Art. no.
10671
Wemefa Drilling Console RHE 130 mm
- High-quality materials
- Fast and secure shipping
- Easy 30-day returns
- Purchase on account: 120-day payment terms
Regular price
3,43 €
Unavailable
In stock
1055 pcs. available
Purchase on account120-day payment terms
Expert supportMon-Fri 7:00 AM - 6:00 PM
Wemefa Drilling Console RHE 130 mm
3,43 €
Drilling Bracket RHE-130 mm
Universal Drilling Bracket
RH Universal Drilling Brackets
RHE version for all panel radiators
with and without hanging tabs.
Product features:
-In combination with
VDI accessory kit 526 and wall clearance
Eccentric mounting = 30 mm,
Performance class 3 according to VDI 6036
-Galvanized metal parts
-18 mm core diameter
-Adjustable eccentric range = 8.5mm
Accessories:
-VDI accessory kit, clamping bracket,
spacers and lift-out protection
Dimensions and details can be found in the price list
in the download area.
Max. load F1: 1000 N
Max. load F2: 500 N
F1+F2 measured at L: 50 mm
Dimension L: 130 mm
PU: 100 pieces
Weight: 0 kg/PU
Universal Drilling Bracket
RH Universal Drilling Brackets
RHE version for all panel radiators
with and without hanging tabs.
Product features:
-In combination with
VDI accessory kit 526 and wall clearance
Eccentric mounting = 30 mm,
Performance class 3 according to VDI 6036
-Galvanized metal parts
-18 mm core diameter
-Adjustable eccentric range = 8.5mm
Accessories:
-VDI accessory kit, clamping bracket,
spacers and lift-out protection
Dimensions and details can be found in the price list
in the download area.
Max. load F1: 1000 N
Max. load F2: 500 N
F1+F2 measured at L: 50 mm
Dimension L: 130 mm
PU: 100 pieces
Weight: 0 kg/PU
