Art. no.
V5000Y0032
Resideo Branch Isolation Valve Combi-3-Plus Brass, Socket, DN32, red, Flow
- High-quality materials
- Fast and secure shipping
- Easy 30-day returns
- Purchase on account: 120-day payment terms
Regular price
61,22 €
Unavailable
In stock
146 pcs. available
Purchase on account120-day payment terms
Expert supportMon-Fri 7:00 AM - 6:00 PM
Resideo Branch Isolation Valve Combi-3-Plus Brass, Socket, DN32, red, Flow
61,22 €
Resideo Balancing valve Kombi-3-Plus
red, for the flow, housing made of dezincification-resistant brass. General draining and differential pressure measurement by means of an adapter via the top section, no attachments on the valve body. Maintenance-free spindle sealing with double O-ring, PTFE seat sealing. DN 10 - 20 universal connection with internal thread according to DIN EN 10226-1 for threaded pipe or for copper and precision steel pipes 10 - 22 mm using compression ring and compression screw. DN 25 - 80 connection with internal thread according to DIN EN 10226-1 for threaded pipe. For pH value of 8 - 9.5.
Medium: Water or water-glycol mixture according to VDI 2035
Housing material: Brass, dezincification-resistant
Nominal size: DN 32
Nominal pressure: PN 16
Version: with internal thread
Kvs value: 13
Medium temperature: -20 °C - 130 °C
Note: Identical in construction to former Honeywell article
Brand: Resideo
Type: Braukmann
red, for the flow, housing made of dezincification-resistant brass. General draining and differential pressure measurement by means of an adapter via the top section, no attachments on the valve body. Maintenance-free spindle sealing with double O-ring, PTFE seat sealing. DN 10 - 20 universal connection with internal thread according to DIN EN 10226-1 for threaded pipe or for copper and precision steel pipes 10 - 22 mm using compression ring and compression screw. DN 25 - 80 connection with internal thread according to DIN EN 10226-1 for threaded pipe. For pH value of 8 - 9.5.
Medium: Water or water-glycol mixture according to VDI 2035
Housing material: Brass, dezincification-resistant
Nominal size: DN 32
Nominal pressure: PN 16
Version: with internal thread
Kvs value: 13
Medium temperature: -20 °C - 130 °C
Note: Identical in construction to former Honeywell article
Brand: Resideo
Type: Braukmann
