Kermi Basic-50 H1448xW35xD599mm QN817, white

Kermi Basic-50
Bathroom and living room radiators
with horizontal
round tubes 24 mm in diameter and
vertical collector tubes 50 x 35 mm as
D-profile. Without visible welds.
Gaps between the tube blocks for
hanging towels.
The fastening is on the
back of the D-profiles. The
fastening set included corresponds to
VDI 6036, requirement class 2.
Requirement class 3 possible upon request.
The wall material must be checked for
sufficient load-bearing capacity.
Can be oriented horizontally, vertically and at a
distance from the wall.
Visible parts of the accessories in
radiator color.
Ready for installation, packed in cardboard and
shrink-wrapped in foil.
Tested according to DIN EN 442. The
construction complies with the former
BAGUV guidelines. Awarded with
the RAL quality mark.
Standard color white (RAL 9016); radiator color concept available at
extra charge.
Chrome-plated version not suitable for rooms
with aggressive/humid atmosphere.
Bathrooms, kitchens, etc.,
as well as places outside the
spray area of showers,
toilets... are not to be understood as rooms
with aggressive/humid atmospheres.
Connections:
2 x G 1/2" internal thread downwards,
2 x G 1/2" internal thread centrally downwards
Ventilation: G 1/4" internal thread to the
rear
Hub spacing: 50 mm center connection
or dependent on overall length
Painting: Two-coat painting according to
DIN 55900,
Primer (ETL), powder coating
(EPS), emission-free even during
heating operation.
Operating pressure: max. 10 bar
Medium: Hot water up to 110 degrees C
Scope of delivery: Fastening set
