KALDEWEI Shower Tray SUPERPLAN 90x90 Alpine White Extra-Flat Base Frame

KALDEWEI SUPERPLAN WITH SHOWER TRAY SUPPORT EXTRA FLAT Shower surface, 900x900x32 mm, Model No: 1848-5

Product description:
Floor-level shower surface with corner drain and accessible from 2 sides without edges

EU TAXONOMY READY thanks to the official publication of EPDs

You can find the current Environmental Product Declaration (EPD) here:
https://www.kaldewei.de/unternehmen/nachhaltigkeit/epd

Steel enamel products stand for sustainability and are 100% recyclable.

The standard white variant of this product
is officially Cradle to Cradle certified® in Silver.

Model: SUPERPLAN WITH SHOWER TRAY SUPPORT EXTRA FLAT
Model No: 1848-5
Outer length (mm): 900
Outer width (mm): 900
Rim height (mm): 32
Depth (mm): 25
Material: KALDEWEI Steel Enamel
Manufacturer: KALDEWEI

Product specification:
Shower surface shape: Square
Installation: raised installation
Warranty: 30 years according to warranty certificate
MADE IN GERMANY
Drain hole (mm): 90
Drain position: corner drain
Earthing lug for potential equalisation.
Weight (kg): 21.80

OPTIONAL Installation:
System-Installation-Box S-IX
Model No: System-Installation-Box SIX: '.........'

Shower tray sound insulation set DWS
Model No: DWS: '.........'

Bathtub connection sound insulation tape WAS 70
Model No: WAS 70: '.........'

Sealing set Floor-level
Model No: Sealing set Floor-level: '.........'

Sealing material
Model No: Sealing accessories: '.........'

Bathtub installation tape WES 130: For sound insulation and separation between product bottom edge and walling
Model No: WES 130: '.........'

Sealing set FLEX
Model No: Sealing set FLEX: '.........'

OPTIONAL Inlet/outlet technology:
Drain cover KA 90: in addition to sets 4103, 4104, 4105
Model No: Drain cover KA 90: '.........'
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

Drain set KA 90 flat: chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4104: '.........'

Drain set KA 90 vertical: chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4105: '.........'

Drain set KA 90 horizontal: chrome drain cover, hair trap included.
Universally applicable for FR and ESR.
Optional accessory: enamelled drain cover for KA 90
Model No: 4103: '.........'

Shower surface colours:
Alpine white: '...........'
Sanitary colours: '...........'
COORDINATED COLOURS COLLECTION: '...........'

OPTIONAL Surfaces:
Anti-slip surface KALDEWEI SECURE PLUS Antislip: '...........'
Easy-care PERL-EFFECT: '...........'
Virtually invisible anti-slip on the standing surface INVISIBLE GRIP: '...........'
Note: Anti-slip surfaces cannot be combined with pearl effect

According to EU Construction Products Regulation (CPR):
CE 15 KBW001 PH/marked according to
DIN EN 14516 - CL1+CL2
Certified surface:
Scratch and impact resistant, chemical resistant,
heat resistant, UV resistant, dimensionally stable,
easy to clean and hygienic.

Safety technical examination:
TÜV Rheinland confirms that KALDEWEI's Antislip/Full-antislip enamelling has
a slip resistance according to assessment group B
for wet barefoot areas (DIN 51097) and
according to assessment group R10 for slip-resistant
properties in workrooms and work areas
with increased risk of slipping (DIN 51130).

Attention: Item number (GTIN) refers to the standard white variant from the product family.
