Sleeve Anchor FSA M6 8/65 S FISCHER

The fischer sleeve anchor FSA-S is an anchor made of electro-galvanised steel with a hexagon head screw for structural fastenings. The FSA-S is installed using time-saving push-through installation. When tightened, the cone is pulled into the expansion sleeve, bracing it against the drill hole wall. The cut-outs absorb the tightening slip like a crumple zone. This draws the attachment part close to the anchoring substrate. The fischer sleeve anchor FSA-S is ideal for fastening non-safety-relevant fixtures such as brackets, handrails, or cable trays in uncracked concrete. Further technical characteristics: · Anchor length: 114mm · Push-through installation: Yes · Thread size (mm): 6mm · Installation torque: 8Nm · Material: Electro-galvanised steel · Min. drill hole depth for push-through installation: 115mm · Min. embedment depth: 35mm · Effective length: 65mm · Professional / DIY: Professional · Washer (outer diameter x thickness): 12 x 1.6mm · VDS approval: Yes · Packaging variant: Folding carton · Max. thickness of the attachment part: 65mm Easy installation due to optimised anchor geometry even in confined spaces. With hexagon head screw. Flush-to-surface dismantling due to detachable screw connection.
