Sleeve anchor FSA M6 8/40 S FISCHER

The fischer Sleeve Anchor FSA-S is an anchor made of electro-galvanized steel with a hexagon head screw for structural fastenings. The FSA-S is installed using time-saving through-fixing installation. When tightened, the cone is pulled into the expansion sleeve, bracing it against the drill hole wall. The cut-outs absorb tightening slip like a crumple zone, pulling the attachment part closer to the anchoring substrate. The fischer Sleeve Anchor FSA-S is ideal for fastening non-safety-relevant fixtures such as brackets, handrails, or cable trays in non-cracked concrete. Further technical characteristics: · Anchor length: 89mm · Through-fixing installation: Yes · Thread size (mm): 6mm · Installation torque: 8Nm · Material: Electro-galvanized steel · Min. drill hole depth for through-fixing installation: 90mm · Min. embedment depth: 35mm · Usable length: 40mm · Professional / DIY: Professional · Washer (outer diameter x thickness): 12 x 1.6mm · VDS approval: Yes · Packaging variant: Folding box · Max. thickness of attached part: 40mm Easy installation due to optimized anchor geometry, even in confined spaces. With hexagon head screw. Flush-to-surface dismantling thanks to detachable screw connection.
