Sleeve Anchor FSA M6 8/40 B FISCHER

The fischer sleeve anchor FSA-B is an anchor made of electrogalvanized steel with nut and washer for structural fastenings made of electrogalvanized steel. The FSA-B is installed using time-saving push-through installation. When tightened, the cone is pulled into the expansion sleeve, bracing it against the drill hole wall. The punch-outs absorb the tightening slip like a crumple zone. This pulls the attachment part against the anchoring base. The fischer sleeve anchor FSA-B is ideal for fastening non-safety-relevant fixtures such as ladders, gates, and temporary fastenings in uncracked concrete. Further technical properties: · Anchor length: 90mm · Push-through installation: Yes · Thread size (mm): 6mm · Installation torque: 8Nm · Material: Electrogalvanized steel · Min. drill hole depth for push-through installation: 90mm · Min. embedment depth: 35mm · Effective length: 40mm · Professional / DIY: Professional · Washer (outer diameter x thickness): 12 x 1.6mm · VdS approval: Yes · Packaging variant: Folding box · Max. thickness of the attachment part: 40mm Easy installation due to optimized anchor geometry, even in confined spaces. With nut and washer. Flush disassembly thanks to removable screw connection.
