High-performance Anchor FH II M8 12/10 B FISCHER

The fischer high-performance anchor FH II B with threaded bolt is a sleeve anchor made of electro-galvanised steel. The anchor is installed using time-saving push-through installation. When the anchor is tightened, the cone is pulled into the expansion sleeve, bracing it against the drill hole wall. The black plastic ring prevents the anchor from spinning and absorbs the tightening slippage. This pulls the attachment part against the anchoring base. The fischer high-performance anchor FH II B with threaded bolt is ideally suited for fastening gratings, steel structures and cable trays in cracked and uncracked concrete. Marketing Claim: The through-bolt anchor with threaded bolt for fastenings with demanding design in cracked concrete. Advantages: International approvals guarantee maximum safety and highest performance. Applications in earthquake zones (Seismic C1 and C2) are also covered by these approvals. The practical fastening with a threaded bolt and nut allows for the dismantling of the attachment part. The ideal interaction of screw shaft and sleeve enables high shear load capacity. This means fewer fastening points are required. The optimised geometry intelligently reduces the setting energy and thus ensures fatigue-free installation. The use of hollow drill bits is regulated in the approval. Top Features: International approvals guarantee maximum safety and highest performance. Also for applications in earthquake zones (Seismic C1 and C2). The ideal interaction of screw shaft and sleeve enables high shear load capacity and fewer fastening points. The optimised geometry intelligently reduces the setting energy and thus ensures fatigue-free installation. Further technical characteristics: · Anchor length: 95mm · Push-through installation: Yes · Thread size (mm): 8mm · ICC approval: Yes · Material: Electro-galvanised steel · Min. drill hole depth for push-through installation: 90mm · Min. embedment depth: 60mm · Usable length: 10mm · Professional / DIY: DIY/Professional · Test marks / approvals: ICC - ES approval, Seismic, Fire protection classification, ETA - European Technical Assessment, VdS approval · Seismic approval: C1 / C2 · Washer (outer diameter x thickness): 22 x 2.5mm · VDS approval: Yes · Packaging variant: Folding box · Max. thickness of the attachment part: 10mm ETA approval for cracked concrete and seismic loads. Fatigue-free installation due to optimised anchor geometry. With threaded bolt. Fewer fastening points due to high shear load capacity. Time-saving push-through installation.
