Heavy-Duty Anchor FH II M10 15/10 B FISCHER

The fischer high-performance anchor FH II B with threaded bolt is a sleeve anchor made of electro-galvanized steel. The anchor is installed using time-saving push-through installation. When the anchor is tightened, the cone is pulled into the expansion sleeve, bracing it against the borehole wall. The black plastic ring prevents the anchor from spinning and absorbs the tightening slip. This pulls the attachment part against the anchoring base. The fischer high-performance anchor FH II B with threaded bolt is ideally suited for fastening grids, steel structures, and cable trays in cracked and uncracked concrete. Marketing Claim: The push-through anchor with threaded bolt for fastenings with demanding design in cracked concrete. Advantages: International approvals guarantee maximum safety and highest performance. These approvals also cover applications in earthquake zones (seismic C1 and C2). The practical fastening via threaded bolt and nut allows for the disassembly of the attachment part. The ideal interaction of screw shaft and sleeve enables high transverse load capacity, thus requiring fewer fastening points. The optimized geometry intelligently reduces installation energy, ensuring power-saving installation. The use of hollow drill bits is regulated in the approval. Top Features: International approvals guarantee maximum safety and highest performance, even in applications in earthquake zones (seismic C1 and C2). The ideal interaction of screw shaft and sleeve enables high transverse load capacity and fewer fastening points. The optimized geometry intelligently reduces installation energy, ensuring power-saving installation. Further technical specifications: · Anchor length: 110mm · Push-through installation: Yes · Thread size (mm): 10mm · ICC approval: Yes · Material: Electro-galvanized steel · Min. drill hole depth for push-through installation: 100mm · Min. embedment depth: 70mm · Effective length: 10mm · Professional / DIY: Professional · Test marks / Approvals: ICC - ES approval, FM (Factory Mutual), Seismic, Fire protection classification, ETA - European Technical Assessment, VdS recognition · Seismic approval: C1 / C2 · Washer (outer diameter x thickness): 25 x 3mm · VDS approval: Yes · Packaging variant: Folding box · Max. thickness of attachment part: 10mm ETA approval for cracked concrete and seismic loads. Power-saving installation due to optimized anchor geometry. With threaded bolt. Fewer fastening points due to high transverse load capacity. Time-saving push-through installation.
