Hinged pipe clamp FKS clamping range 50-55mm connection M8 galvanized steel

The fischer plastic pipe clamp FKS 50-55. Quick-release fastener enables simple and time-saving installation of pipelines. The spacer sleeves on the locking screw ensure that the pipes can slide during thermal expansion. Connection nut with M8 thread for attaching threaded rods or hanger bolts. Pipe clamp screws with loss protection. Marketing claim: The one-piece hinged pipe clamp with quick-release fastener for plastic and multilayer pipes. Advantages: The spacer sleeves on the locking screw ensure that the pipes can slide during thermal expansion. The secure fit of the sound insulation insert prevents it from falling out during pipe adjustment. The compact design of the pipe clamp allows for easy, subsequent insulation. The screw's loss protection ensures problem-free installation. The quick-release fastener enables simple and time-saving installation. Quick-release fastener enables simple and time-saving installation. Spacer sleeves on the locking screw. Screw with loss protection. Sound insulation insert. Further technical properties: · Connection thread: M8 · Clamp band width: 20mm · Clamp band width x thickness: 20 x 1.5mm · Installation torque: 2Nm · Professional / DIY: Professional · Wrench size: 13mm · Clamping range: 50 - 55mm · Clamping range from - to: 50mm · Clamp band thickness: 1.5mm · Packaging variant: Folding box · Max. recommended static load (central tensile): 0.9kN
