Torque Wrench 5143-3CT 1/2″ 100-400 Nm HAZET

User-friendly reversible ratchet. For high-torque applications: axle central screws on FIAT Ducato and MERCEDES-BENZ Sprinter, wheel bearings on, for example, OPEL Movano and PEUGEOT Boxer, bearing blocks on agricultural machinery and gearbox blocks on commercial vehicles. By enabling the use of 1/2" (12.5 mm) socket wrench inserts/extensions, torque-controlled screw connections from 100 to 400 Nm in craft and industrial production areas, e.g., with threads from M12 to M16 (strength class 12.9) or M16 to M24 (strength class 5.6) with confined access, e.g., for flange or machine screw connections, can also be actuated – SYSTEM 5000-3CT – Accuracy ± 3% of scale value (in actuation direction for right-hand tightening) (5107-3CT ± 4% accuracy of scale value). For left-hand tightening, use our torque wrenches with insert holder. Secure: tactile (short-stroke release), acoustic (flex element). Designed for tough workshop use. Wide range of applications for controlled screw tightening in tire service, two-wheeler, passenger car, commercial vehicle applications, and various applications in industry and trade. Optimized sealing ring for protection against foreign bodies. Ratchet repair kit for customer-oriented self-assembly enables decades of use. Handle with more grip for easier power transmission. Adjustment aid through detents for optimized user guidance ensures safe and quick setting of the desired torque value by turning the handle. Secure locking of the adjustment values by detent function on the rotary ring. Triangular shape prevents uncontrolled rolling away. Lock symbols indicate the respective locking status. Possibility of attaching a rope loop through openings on the locking rotary ring. Easy-to-read, high-contrast scale. Permanent readability thanks to laser inscription on the scale sleeve. Integrated reversible lever. 5121-3CT – 5123-3CT: Reversible lever with free-wheel function – reduces risk of injury and malfunctions. With calibration certificate and serial number. Supplied in robust Hexa-Drehpack. DIN EN ISO 6789-2:2017, DIN 3120, ISO 1174-1. Made in Germany. Drive: 1/2 inch (12.5 mm) square solid. Dimensions / length: 790 mm. Net weight (kg): 3.6 kg. Torque range min-max: 100–400 Nm. Accuracy: 3%. Scale division (Nm): 2.5 Nm. Actuating force min.-max. kg: 14.8–60.3 kg. Number of teeth: 32 (actuating angle 11.25°). Head thickness a: 28.5 mm. Head width b: 64 mm. No more turning back: In long-term endurance tests, it has been proven that with HAZET torque wrenches of the 5000 and 6000 series, it is not necessary to turn back to the smallest scale value. SYSTEM 5000-3CT workshop torque wrench 1–800 Nm – with reversible ratchet – accuracy ±3/4%. Further technical specifications: Number of teeth: 32 teeth. Tightening torque max Nm: 400 Nm. Tightening torque min Nm: 100 Nm. Actuating force min. kg: 14.8 kg. Actuating angle: 11.25°. Spare part: 1016/6, SP-20, 5143/8. Accuracy: 3%. Head width b: 64 mm. Head thickness a: 28.5 mm. Net weight (kg): 3.6 kg. Standard: DIN EN ISO 6789-2:2017, DIN 3120, ISO 1174-1. Service package: SP-20. Actuating force max. kg: 60.3 kg.
