Insulation fastener TermoFix H 50 FISCHER

The fischer TermoFix H plate elements allow all common insulation boards to be flexibly fastened to wood and panel building materials with standard screws. By combining different shaft lengths with different screw lengths, any insulation thickness can be securely fastened. Marketing claim: The plate element for use with standard screws. Advantages: Very high cost-effectiveness due to different shaft lengths. This allows the screw length to be reduced if necessary. With the TermoFix H 50 · 90 and 150 plate elements, the plate is closed with the injection-molded cap. The closure creates an air column above the screw head. This reduces heat transmission losses. For the TermoFix H 10 plate element, the polystyrene plugs are included. Can be combined with the DT 90 · DT 110 and DT 140 insulation plates. Flexibly combinable with different screw lengths. Optimal plaster adhesion due to open plate geometry. Sealing plug integrated directly into the plate element. Further technical properties: · Type: H 50 · Color: green · Shaft length: 69mm · Plate closure: Sealing cap (injection-molded) · VDS approval: Yes
