Concrete Screw UltraCut FBS II 8mm SW 13 L120mm ETA Approval Yes FISCHER

The fischer concrete screw UltraCut FBS II US R with the specially hardened red tip is a high-performance anchoring solution for quick installation. The concrete screw with the pre-assembled washer is ideal for outdoor applications or in damp rooms. The European Technical Assessment for cracked and uncracked concrete, as well as for seismic loads and fire suitability for fire resistance class R 120, guarantee an additional plus in safety. The sawtooth geometry enables quick and effort-saving installation. No drill hole cleaning is required when installing in ceilings and floors. The expansion-pressure-free anchoring allows for minimal edge and axial distances. Marketing Claim: The high-performance concrete screw for maximum installation comfort outdoors. Advantages: The specially hardened red tip ensures noticeably faster and safer installation. The stainless steel version of the concrete screw ensures very high corrosion protection and thus enables use in damp rooms and outdoors. The special sawtooth geometry allows for quick cutting into concrete. For vertical installation (in ceilings and floors) and the use of hollow drill bits, drill hole cleaning is not required. For drilling into the floor, drilling must be 3 times the drill diameter deeper. The ETA assessment covers use in cracked concrete, as well as seismic performance categories C1 and C2. The approval-compliant adjustability allows the concrete screw to be loosened twice, to underlay and/or align the attachment part. Three approved embedment depths allow for use in a wide range of applications, thus ensuring great flexibility. The short version with reduced embedment depth allows for a shallow drill hole depth, quick installation, and fewer rebar hits. The concrete screw FBS II 6-10 made of galvanised steel, multi-coated steel CP, and stainless steel has an ETA for masonry bricks Mz (EN771-1), calcium silicate solid bricks KS (EN771-2), and perforated calcium silicate bricks KSL (EN771-2) for flexible use in various substrates. When installing the concrete screw FBS II 6-10 made of galvanised steel, multi-coated steel, and stainless steel in masonry, it can also be installed between joints and in groups, on plastered masonry substrates. Top Features: The specially hardened red tip ensures noticeably faster and safer installation. The stainless steel version of the concrete screw ensures very high corrosion protection and thus enables use in damp rooms and outdoors. The approval-compliant adjustability allows the concrete screw to be loosened twice, to underlay and/or align the attachment part. Further technical properties: · Material: Stainless steel · Head-Ø: 18mm · Min. drill hole depth for push-through installation: 130mm · Nominal embedment depth / fixture thickness: 50 / 70mm · Professional / DIY: Professional · Wrench size: 13mm · Screw dimensions: 10.0 x 120mm · Screw diameter: 8mm
