Concrete screw UltraCut FBS II 8 mm TX40 / SW 13 L150mm ETA approval Yes FISCHER

The fischer UltraCut FBS II is the concrete screw for maximum installation convenience. The special sawtooth geometry allows for quick cutting into concrete. For ceiling or floor installations, no drill hole cleaning is necessary. Thanks to national approval, multiple use for temporary anchoring, e.g., in formwork construction, is regulated. For installing the masonry screw, an impact wrench with an impact wrench-compatible socket or a special TX bit is recommended. The concrete screw is ideal for fastening railings, impact protection, consoles, or formwork supports, for example. Marketing Claim: The powerful concrete screw for maximum installation convenience. Advantages: Greatest flexibility in load and fixture thickness due to up to three approved embedment depths. The special sawtooth geometry allows for quick cutting into concrete. For vertical installation (in ceilings and floors) and the use of hollow drills, drill hole cleaning is not required. For drilling into the floor, drilling must be 3x the drill diameter deeper. The expansion-pressure-free anchoring (undercut) ensures minimal edge and axial distances. The ETA assessment covers use in cracked concrete, as well as seismic performance categories C1 and C2. The approval-compliant adjustability allows the concrete screw to be loosened twice, and the fixture to be shimmed and/or aligned. National approval regulates multiple use for temporary anchoring (e.g., formwork construction). The concrete screw FBS II 6-10 made of electro-galvanized steel, multi-coated steel CP, and stainless steel has an ETA for masonry bricks Mz (EN771-1), calcium silicate solid brick KS (EN771-2), and calcium silicate perforated brick KSL (EN771-2) for flexible use in different substrates. When installing the concrete screw FBS II 6-10 made of electro-galvanized steel, multi-coated steel, and stainless steel in masonry, installation can also be done between the joints and in groups, on plastered masonry substrates. Top Features: Greatest flexibility in load and fixture thickness due to up to three approved embedment depths. The special sawtooth geometry allows for quick cutting into concrete. The approval-compliant adjustability allows the concrete screw to be loosened twice, and the fixture to be shimmed and/or aligned. Further technical properties: · Material: Electro-galvanized steel · Bit size (TX): 40 · DIBT approval: Yes · Head Ø: 18mm · Min. drill hole depth for push-through installation: 160mm · Nominal embedment depth / fixture thickness: 50 / 100mm · Professional / DIY: Professional · Wrench size: 13mm · Screw dimension: 10.0 x 150mm · Screw diameter: 8mm The powerful concrete screw for maximum installation convenience in outdoor areas.
